Practical 6 - Bringing it All Together

#include <stdio.h>
#include <string.h>

#include "xparameters.h"
#include "netif/xadapter.h"
#include "xuartps_hw.h"
#include "xil_printf.h"
#include "FreeRTOS.h"
#include "task.h"

#include "lwip/sockets.h"
#include "lwipopts.h"
#include <lwip/ip_addr.h>
#include <lwip/tcp.h>
#include <lwip/udp.h>

#define THREAD_STACKSIZE 1024
#define PORT 51000

//Put your MAC address here!
unsigned char mac_ethernet_address[] = { 0xxx, 0xxx, 0xxx, 0xxx, 0xxx, 0xxx};

//Function Prototypes
void network_init(unsigned char* mac_address, lwip_thread_fn app);
void application_task(void *);
void udp_get_handler(void *arg, struct udp_pcb *pcb, struct pbuf *p, const ip_addr_t *addr, u16_t port);

//------

int main()
{
	//Initialise the network with our MAC address, and the function that should be started as a FreeRTOS task
	network_init(mac_ethernet_address, application_task);

	vTaskStartScheduler(); //Start the scheduler

	//we will only get to here if someone calls vTaskEndScheduler()
	return 0;
}

void application_task(void *p) {
    //This task will set things up and then remove itself once that is done
	xil_printf("application_task started\n\r");

	//Bind a network receiver as we did before
	struct udp_pcb *recv_pcb = udp_new();
	udp_bind(recv_pcb, IP_ADDR_ANY, PORT);
	udp_recv(recv_pcb, udp_get_handler, NULL);

    //Create any other tasks you might need here
    //...
    //...

	vTaskDelete(NULL); //Set up complete so delete ourselves
}

void udp_get_handler(void *arg, struct udp_pcb *pcb, struct pbuf *p, const ip_addr_t *addr, u16_t port) {
    if (p) {
        char msg[p->len + 1];
        memcpy(msg, p->payload, p->len);
        msg[p->len] = '\0';
        printf("Message: %s\n", msg);
        pbuf_free(p);
    }
}

#include <stdio.h>
#include "xparameters.h"
#include "netif/xadapter.h"
#include "xil_printf.h"

#include "lwip/dhcp.h"
void lwip_init();

#define THREAD_STACKSIZE 1024

//Function prototypes
void print_ip(const char *msg, const ip_addr_t *ip);
void network_thread(void *p);
int network_startup_task();

//Structures and globals
static struct netif server_netif;
struct netif *echo_netif;
unsigned char* mac_addr;
lwip_thread_fn application_task;
TaskHandle_t startuptask, nettask, apptask, rcv_task;

//---------------

//Initialise network task
//This is called by user code to provide the mac address we should use,
//and the code that we should run once the network is ready.
void network_init(unsigned char* mac_address, lwip_thread_fn app) {
	mac_addr = mac_address;
	application_task = app;
	xTaskCreate((lwip_thread_fn) network_startup_task, "startup_task", THREAD_STACKSIZE, NULL, DEFAULT_THREAD_PRIO, &startuptask);
}

//Created by network_init(). Initialises lwIP, runs DHCP, and once connected, starts the application_task that the user provided
//when they called network_init
int network_startup_task()
{
    lwip_init();

    //Create lwIP's network handling thread (as described by lwIP documentation)
    xTaskCreate(network_thread, "nw_task", THREAD_STACKSIZE, NULL, DEFAULT_THREAD_PRIO, &nettask);

    //This task just waits until we get an IP address via DHCP, then creates our application task
    while (1) {
    	vTaskDelay(DHCP_FINE_TIMER_MSECS / portTICK_RATE_MS); //wait 500ms
		if (server_netif.ip_addr.addr) { //Do we have an IP address?
			xil_printf("DHCP request success\r\n");
			print_ip("Board IP: ", &server_netif.ip_addr);
			print_ip("Netmask : ", &server_netif.netmask);
			print_ip("Gateway : ", &server_netif.gw);
			xil_printf("\r\n");
			xTaskCreate(application_task, "app_task", THREAD_STACKSIZE, NULL, DEFAULT_THREAD_PRIO, &apptask);
			break;
		}
	}

    //DHCP is connected and we've created the main task so delete ourselves
    vTaskDelete(NULL); //Passing NULL says to delete this task
    return 0;
}

//lwIP's network handling thread (as described by lwIP documentation)
//Started from the network_startup_task
void network_thread(void *p)
{
    struct netif *netif = &server_netif;
    ip_addr_t ipaddr, netmask, gw;
    int mscnt = 0;

	ipaddr.addr = 0;
	gw.addr = 0;
	netmask.addr = 0;

    // Add our network interface to lwIP and set it as default
    if (!xemac_add(netif, &ipaddr, &netmask, &gw, mac_addr, XPAR_XEMACPS_0_BASEADDR)) {
    	xil_printf("Error adding network interface\r\n");
    	return;
    }
    netif_set_default(netif);
    netif_set_up(netif);

    // Start packet receive thread, this is part of lwIP
    xTaskCreate((void(*)(void*))xemacif_input_thread, "xemacif_input_thread", THREAD_STACKSIZE, netif, DEFAULT_THREAD_PRIO, &rcv_task);

    // Start DHCP. This task will now loop forever calling dhcp_fine_tmr and dhcp_coarse_tmr every so often
    xil_printf("\r\nStart DHCP lookup...\r\n");
    dhcp_start(netif);
    while (1) {
		vTaskDelay(DHCP_FINE_TIMER_MSECS / portTICK_RATE_MS);
		dhcp_fine_tmr();
		mscnt += DHCP_FINE_TIMER_MSECS;
		if (mscnt >= DHCP_COARSE_TIMER_SECS*1000) {
			dhcp_coarse_tmr();
			mscnt = 0;
		}
	}

    return;
}

void print_ip(const char *msg, const ip_addr_t *ip)
{
	xil_printf(msg);
	xil_printf("%d.%d.%d.%d\n\r", ip4_addr1(ip), ip4_addr2(ip), ip4_addr3(ip), ip4_addr4(ip));
}
